LumaSense Introduces the World’s First Industrial Grade 2-Color Infrared Pyrometer with Thermal Imaging Capabilities

The ISR 6-TI Advanced pyrometer uses a built-in video camera with infrared filter to improve manufacturing processes in metals, glass, and other heat-dependent manufacturing industries.

LumaSense Technologies added the integrated ISR 6-TI Advanced to their IMPAC pyrometer and imaging portfolio for increased control and optimization of manufacturing processes in metals, glass, and other materials industries.

The ISR 6-TI Advanced is a true break-through by combining pyrometry with infrared imaging technology to produce “Relative” thermal images. “Relative” thermal images are produced by measuring the temperature of the center spot with a ratio pyrometer and using an infrared filter to show an auto-calibrated thermal image based on the highly accurate ratio pyrometer temperature reading.

The system is based on the proven ISR 6 Advanced pyrometer and a video camera that utilizes a short wavelength infrared filter. The resulting ISR 6-TI Advanced system operates in a short wavelength (around 1 μm) for accurate and reliable temperature measurements between 700 °C and 1800 °C. The analog video output signal is converted to USB and fed to a PC using LumaSense’s InfraWin software.

The InfraWin software generates and shows a “Relative” thermal image from this signal. LumaSense’s InfraWin software also provides temperature, data logging, and analysis features. The ISR 6-TI Advanced paints a more-accurate picture for identifying potential issues before they lead to problems that impact process performance, a key benefit for materials manufacturers running heat-dependent processes.

This innovative hybrid pyrometer solution is ideal for industries where it’s critical to know the temperature and ensure uniformity across an object at that temperature. It is accurate and easy to use by offering a single user interface for the pyrometer and thermal imaging function. Moreover there is no mechanical alignment required between the thermal image and the pyrometer, which would be needed if you were working with two different systems. As such, many processes in metals and glass making that use a single pyrometer to measure temperature can be improved with this innovative technology by seeing the uniformity across the object rather than just one point.
